Introduction

OERSTED™, a 2D/RS time-harmonic eddy current solver from INTEGRATED Engineering Software, delivers the power and performance needed to accomplish transient EM field solving. Using our innovative Boundary Element Method (BEM) technology with the Finite Element Method (FEM) solver, OERSTED distinguishes itself in magnetic design problems that require large open field analysis, exact modeling of boundaries and in applications where dealing with small skin depths are critical.

OERSTED™ provides powerful tools for magnetic field analysis, and calculation of resultant parameters such as force, torque, induced voltages, displacement current, flux linkage, induced voltage, power, impedance and currents.

Our powerful parametric solvers allow designers to automatically vary and experiment with geometry, materials and sources. Thanks to the post processing tools available in OERSTED™, designers can set up calculations and graphical analysis for any parameters not available as standard output – reducing the tedious, repetitive task of fine–tuning multiple design parameters.

Features

  • At no extra cost, our software packages include:
    • Choice of solvers: To ensure you have confidence in the solution and for independent verification, both BEM and FEM methods are included in the same software package to suit your specific application needs. Not every solver fits every application, no “one size fits all”.
    • Choice of optimization tools: Parametric Analysis for those who need fast and easy optimization with a short learning curve. API and Scripting give more power to advanced users. Both tools are available in the same package.
    • Built-in material libraries: Customize and create your own library for easy access to the materials you use.
    • Integration with MATLAB®: Users' MATLAB code can include function calls to the INTEGRATED API to build geometry, assign physical parameters, solve, and obtain results.
    • Parallelization: When used on 64-bit computers, this permits full utilization of the available RAM to dramatically increase speed of solution and post-processing.
  • Intuitive interface that can be easily customized according to user preferences (overall appearance, toolbars, solvers, backgrounds, defaults, etc.)
Benchmarks:
Benchmark Problems for Simulating Electric Fields Near Sharp Corner

ISEI_2008
